EAN Code: 3245060371715

Weight: 0.012 kg

Packaging quantity: 50 pcs.

Mounting method: DIN rail (top hat rail) 35 mm

Number of clamp positions per level: 2

Number of levels: 1

Connection position: Sideways

Operation temperature: 40 oC

Material insulation body: Thermoplastic

Internally connected stages: False

Length: 52.5 mm

Height at lowest possible mounting height: 46.5 mm

Inflammability class of insulation material acc. with UL94: V2

Colour: Green/yellow

Closing plate required: True

Connectable conductor cross section fine-strand with cable end sleeve: 4 mm2

Connectable conductor cross section fine-strand without cable end sleeve: 6 mm2

Connectable conductor cross section multi-wired: 4 mm2

Connectable conductor cross section solid-core: 6 mm2

Type of electrical connection 2: Screw connection

Explosion-tested version 'Ex e': True

Type of electrical connection 1: Screw connection

Rated voltage: 800 V

Rated current In: -
