EAN Code: 3245060371609

Weight: 0.007 kg

Packaging quantity: 60 pcs.

Connectable conductor cross section fine-strand with cable end sleeve: 2.5 mm2

Connectable conductor cross section fine-strand without cable end sleeve: 4 mm2

Height at lowest possible mounting height: 46.5 mm

Width/grid dimension: 5 mm

Inflammability class of insulation material acc. with UL94: V2

Operation temperature: 40 oC

Colour: Grey

Closing plate required: True

Length: 52.5 mm

Connectable conductor cross section solid-core: 4 mm2

Explosion-tested version 'Ex e': True

Type of electrical connection 1: Screw connection

Rated voltage: 800 V

Rated current In: 24 A

Number of clamp positions per level: 2

Number of levels: 1

Connection position: Sideways

Type of electrical connection 2: Screw connection

Material insulation body: Thermoplastic

Internally connected stages: False

Mounting method: DIN rail (top hat rail) 35 mm
