EAN Code: 3414970400567

Weight: 0.572 kg

Packaging quantity: 1 pcs.

Number of main contacts as normally open contact: 3

Number of normally closed contacts as main contact: 0

Type of electrical connection of main circuit: Cable clamp

Number of auxiliary contacts as normally closed contact: 2

Rated control supply voltage Us at AC 60HZ: 253 V

Rated control supply voltage Us at AC 50HZ: 253 V

Rated operation power Ie at AC-4, 400 V: 7.5 kW

Rated operation current Ie at AC-4, 400 V: 17 A

Rated operation power at AC-3, 400 V: 18.5 kW

Modular version: True

Rated operation current Ie at AC-3, 400 V: 40 A

Rated operation current Ie at AC-1, 400 V: 60 A

Voltage type for actuating: AC

Rated control supply voltage Us at DC: -
