EAN Code: 3414970399960

Weight: 0.364 kg

Packaging quantity: 1 pcs.

Number of auxiliary contacts as normally open contact: 1

Rated operation power Ie at AC-4, 400 V: 4 kW

Rated operation current Ie at AC-4, 400 V: 11 A

Rated operation power at AC-3, 400 V: 7.5 kW

Modular version: True

Rated operation current Ie at AC-3, 400 V: 18 A

Voltage type for actuating: AC

Number of main contacts as normally open contact: 3

Number of normally closed contacts as main contact: 0

Type of electrical connection of main circuit: Cable clamp

Number of auxiliary contacts as normally closed contact: 1

Rated control supply voltage Us at AC 60HZ: 253 V

Rated control supply voltage Us at AC 50HZ: 253 V

Rated control supply voltage Us at DC: -
