EAN Code: 3414970388254

Weight: 0.129 kg

Packaging quantity: 10 pcs.

Degree of protection (IP): IP20

Additional equipment possible: True

Width in number of modular spacings: 1

Built-in depth: 44 mm

Concurrently switching N-neutral: False

Pollution degree: 2

Voltage type: AC

Current limiting class: 3

Rated current: 13 A

Rated voltage: 230 V

Release characteristic: C

Rated short-circuit breaking capacity Icn EN 60898 at 230 V: 6 kA

Number of poles (total): 1

Suitable for flush-mounted installation: True

Frequency: 60 Hz

Number of protected poles: 1

Connectable conductor cross section solid-core: -

Ambient temperature during operating: -

Rated short-circuit breaking capacity Icn EN 60898 at 400 V: -

Over voltage category: -

Rated insulation voltage Ui: 500 V

Connectable conductor cross section multi-wired: -

Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V: -

Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V: -
