EAN Code: 4751033951376

Weight: 0.29 kg

Packaging quantity: 2 pcs.

Connectable conductor cross section fine-strand without cable end sleeve: 120 mm2

Connectable conductor cross section fine-strand with cable end sleeve: 120 mm2

Connectable conductor cross section solid-core: -

Connectable conductor cross section multi-wired: 150 mm2

Rated current In: 640 A

Rated voltage: 750 V

Type of electrical connection 1: Screw connection

Type of electrical connection 2: -

Connection position: Sideways

Number of clamp positions per level: -

Mounting method: DIN rail (top hat rail) 35 mm

Material insulation body: Thermoplastic

Operation temperature: 80 oC

Inflammability class of insulation material acc. with UL94: V0

Width/grid dimension: 51 mm

Height at lowest possible mounting height: 54 mm

Length: 84 mm

Explosion-tested version 'Ex e': False

Closing plate required: False

Colour: Green/yellow

Internally connected stages: -
