EAN Code: 3245060442132

Weight: 1.972 kg

Packaging quantity: 1 pcs.

Primary voltage 1: 215 V

Secondary voltage 1: 24 V

Primary voltage 2: 230 V

Primary voltage 6: 415 V

Short-circuit-proof: False

Rated apparent power: 100 VA

Primary voltage 3: 245 V

Modular version: True

Primary voltage 4: 385 V

Primary voltage 5: 400 V

Depth: 113 mm

Degree of protection (IP): IP2X

Ring core: False

Suitable for mounting on PCB: False

Type of insulation material acc. IEC 85: B

Relative short circuit voltage: 8.5 %

Width: 94 mm

Height: 94 mm

Built as isolating transformer: False

Built as energy saving transformer: False

Built as safety transformer: True

Secondary voltage 10: -

Secondary voltage 2: -

Primary voltage 7: -

Secondary voltage 7: -

Primary voltage 9: -

Primary voltage 8: -

Secondary voltage 8: -

Secondary voltage 9: -

Secondary voltage 4: -

Secondary voltage 5: -

Conductor material: -

Secondary voltage 6: -

Secondary voltage 3: -

Primary voltage 10: -
