EAN Code: 3245064020633

Weight: 0.337 kg

Packaging quantity: 1 pcs.

Built-in depth: 44 mm

Mounting method: DIN rail

Width in number of modular spacings: 4

Additional equipment possible: False

Frequency: 50 Hz

Degree of protection (IP): IP20

Short-circuit breaking capacity (Icw): 10 kA

Surge current capacity: 0.25 kA

Construction size (in accordance with DIN 43880): 1

Selective protection: False

Short-time delayed tripping: False

Rated fault current: 30 A

Leakage current type: AC

Rated voltage: 400 V

Rated current: 40 A

Number of poles: 4

Connectable conductor cross section multi-wired: 35 mm2

Connectable conductor cross section solid-core: 50 mm2

Pollution degree: 2

With interlocking device: True

Rated insulation voltage Ui: 500 V

Ambient temperature during operating: 60 oC
