EAN Code: 3414970368218

Weight: 0.444 kg

Packaging quantity: 4 pcs.

Current limiting class: 3

Voltage type: AC

Rated voltage: 400 V

Rated current: 63 A

Number of poles (total): 3

Suitable for flush-mounted installation: True

Release characteristic: C

Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V: 10 kA

Rated short-circuit breaking capacity Icn EN 60898 at 230 V: 10 kA

Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V: 6 kA

Additional equipment possible: False

Number of protected poles: 3

Degree of protection (IP): IP20

Built-in depth: 44 mm

Width in number of modular spacings: 3

Pollution degree: 2

Concurrently switching N-neutral: False

Frequency: 60 Hz

Rated short-circuit breaking capacity Icn EN 60898 at 400 V: 6 kA

Connectable conductor cross section solid-core: -

Ambient temperature during operating: -

Over voltage category: -

Rated insulation voltage Ui: 500 V

Connectable conductor cross section multi-wired: -
