EAN Code: 5907484330218

Weight: 0.056 kg

Packaging quantity: 36 pcs.

Mounting method: Flush mounted (plaster)

Shape: Round

Construction type: Built-in installation box (device box)

Model: Double

Provided with revolving ring: False

Can be coupled: False

Equipped with: None

Diameter: 68 mm

Length: 142 mm

Width: 68 mm

Depth: 48 mm

Internal depth: 46 mm

For number of electric fittings: 0

Mounting switching equipment: Screw or spread out

With screws: True

Housing feed-through by break-out opening: True

Housing feed-through by seal membrane: False

Housing feed-through by nozzle: True

Housing feed-through by step membrane: False

For tubediameter: 20 mm

Pipe locking: False

Pipe locking optional: False

Inlet from the rear: True

Number of inlets: -

Number of included spouts: 0

Material: Plastic

Halogen free: True

Surface protection: Other

Colour: Red

Degree of protection (IP): IP30

Cover: None

Cover attachment: Not applicable

Sealable: False

Circuit integrity: -

With screening: False

Wind proof: False

Max. conductor cross section: -

Number of poles of the clamp: -

Clamp position fixed: False

Luminaire hook mounting: False

Nozzle: None

With nail lugs: True

Special application: None
