EAN Code: 5907484332175

Weight: 0.0104 kg

Packaging quantity: 25 pcs.

Thread type: Metric

Nominal thread size metric/PG: 20

Nominal thread size inch/gas pipe thread: Other

Pitch thread: 1.5 mm

Thread length: 9.5 mm

Wrench width: 24 mm

Hexagon angular dimension: 27 mm

Suitable for cable diameter: 12 mm

Material: Plastic

Material quality: Polyamide (PA)

Surface protection: Other

Halogen free: True

Glass-fibre reinforced: True

Degree of protection (IP): IP67

Shock resistant: True

Colour: Light grey

RAL-number: 7035

Bend radius protection/trumpet flare: False

With locknut: True

Model: Straight

Multi seal area: False

Flat cable coupling: False

With strain relief: False

Type of sealing: Sealing ring

Separable screw gland: True

Working temperature: 80 oC

Explosion-tested version: False

For Ex-zone gas: None

For Ex-Zone dust: None
