EAN Code: 3245060800536

Weight: 0.095 kg

Packaging quantity: 30 pcs.

Nozzle: None

Luminaire hook mounting: False

With nail lugs: False

Surface protection: Untreated

Material: Plastic

Degree of protection (IP): IP20

Colour: Yellow

Sealable: False

Pipe locking: False

Number of inlets: 10

Inlet from the rear: True

Max. conductor cross section: 0 mm2

Wind proof: False

Clamp position fixed: False

Number of poles of the clamp: 0

Cover attachment: Other

Cover: None

With screening: False

Circuit integrity: None

Equipped with: None

Construction type: Device connection box (round/square)

Diameter: 67 mm

Shape: Oval

Mounting method: Hollow wall

With screws: True

Mounting switching equipment: Screw or spread out

Suitable for cable diameter: 25 mm

Internal depth: 48 mm

Width: 73 mm

Halogen free: True

For number of electric fittings: 8

For tubediameter: Other

Model: Other

Cover model: None

Number of included spouts: -

Housing feed-through by nozzle: -

Depth: -

Housing feed-through by seal membrane: -

Housing feed-through by break-out opening: -

Pipe locking optional: -

Provided with revolving ring: -

Can be coupled: -

Housing feed-through by step membrane: -

Special application: -
