EAN Code: 3838895502388

Weight: 1.4 kg

Packaging quantity: 1 pcs.

Rated permanent current Iu: 125 A

Rated voltage: -

Rated short-circuit breaking capacity lcu at 400 V, 50 Hz: 25 kA

Overload release current setting: 125 A

Adjustment range short-term delayed short-circuit release: -

Adjustment range undelayed short-circuit release: 1250 A

Integrated earth fault protection: True

Type of electrical connection of main circuit: Screw connection

Device construction: Built-in device fixed built-in technique

Suitable for DIN rail (top hat rail) mounting: -

DIN rail (top hat rail) mounting optional: -

Number of auxiliary contacts as normally closed contact: -

Number of auxiliary contacts as normally open contact: -

Number of auxiliary contacts as change-over contact: -

With switched-off indicator: True

With under voltage release: -

Number of poles: 4

Position of connection for main current circuit: EV009502

Type of control element: Rocker lever

Complete device with protection unit: -

Motor drive integrated: False

Motor drive optional: True

Degree of protection (IP): IP20
