EAN Code: 5908312597308

Weight: 0.129 kg

Packaging quantity: 1 pcs.

Type of electric connection: Screw connection

With detachable clamps: False

Single-phase under voltage possible: False

Three-phase under voltage possible: True

Single-phase over voltage possible: False

Three-phase over voltage possible: True

Single-phase hysteresis possible: True

Three-phase hysteresis possible: True

Contains function DC-under voltage: False

Contains function DC-over voltage: False

Contains function DC-voltage hysteresis: False

Voltage measurement range 1: -

Voltage measurement range 2: 260 V

Type of voltage measurement range: AC

Rated control supply voltage Us at AC 50HZ: 230 V

Rated control supply voltage Us at AC 60HZ: -

Rated control supply voltage Us at DC: -

Voltage type for actuating: AC

Response value voltage: 260 V

Min. adjustable delay-on energization time: -

Max. permitted delay-on energization time: -

Min. adjustable off-delay time: 0.1 s

Max. permitted off-delay time: 10 s

Number of contacts as normally closed contact: -

Number of contacts as normally open contact: 1

Number of contacts as change-over contact: -

Width: 52.5 mm

Height: 90 mm

Depth: 65 mm
