EAN Code: 3838895717959

Weight: 0.228 kg

Packaging quantity: 1 pcs.

Version as main switch: True

Version as maintenance-/service switch: True

Version as safety switch: True

Version as emergency stop installation: True

Version as reversing switch: -

Max. rated operation voltage Ue AC: 690 V

Rated operating voltage: -

Rated permanent current Iu: 40 A

Rated permanent current at AC-21, 400 V: -

Rated operation power at AC-3, 400 V: -

Rated short-time withstand current lcw: -

Rated operation power at AC-23, 400 V: 18,5 kW

Switching power at 400 V: -

Conditioned rated short-circuit current Iq: -

Number of auxiliary contacts as normally closed contact: -

Number of auxiliary contacts as normally open contact: -

Number of auxiliary contacts as change-over contact: -

Motor drive optional: False

Motor drive integrated: False

Voltage release optional: False

Device construction: -

Suitable for ground mounting: True

Suitable for front mounting 4-hole: -

Suitable for front mounting center: -

Suitable for distribution board installation: True

Suitable for intermediate mounting: True

Colour control element: -

Type of control element: Turn button

Interlockable: -

Type of electrical connection of main circuit: Frame clamp

Degree of protection (IP), front side: IP20
