EAN Code: 7890355108024

Weight: 0.295 kg

Packaging quantity: 1 pcs.

Rated control supply voltage Us at AC 50HZ: 230 V

Rated control supply voltage Us at AC 60HZ: 230 V

Rated control supply voltage Us at DC: 230 V

Voltage type for actuating: AC

Rated operation current Ie at AC-1, 400 V: 25 A

Rated operation current Ie at AC-3, 400 V: 12 A

Rated operation power at AC-3, 400 V: 5,5 kW

Rated operation current Ie at AC-4, 400 V: -

Rated operation power Ie at AC-4, 400 V: -

Modular version: False

Number of auxiliary contacts as normally open contact: 1

Number of auxiliary contacts as normally closed contact: 0

Type of electrical connection of main circuit: Frame clamp

Number of normally closed contacts as main contact: 0

Number of main contacts as normally open contact: 3
