EAN Code: 3838895328070

Weight: 0.25 kg

Packaging quantity: 2 pcs.

Release characteristic: C

Number of poles (total): 1

Number of protected poles: -

Rated current: 100 A

Rated voltage: 230 V

Rated short-circuit breaking capacity Icn EN 60898 at 230 V: -

Rated short-circuit breaking capacity Icn EN 60898 at 400 V: -

Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V: 20 kA

Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V: 20 kA

Current limiting class: 3

Frequency: 50 Hz

Concurrently switching N-neutral: -

Suitable for flush-mounted installation: -

Over voltage category: -

Pollution degree: -

Width in number of modular spacings: 1,5

Built-in depth: 75 mm

Additional equipment possible: True

Degree of protection (IP): IP20

Rated short-circuit breaking capacity EN 60898: 10 kA

Rated short-circuit breaking capacity IEC 60947-2: 20 kA
