EAN Code: 5908312592068

Weight: 0.067 kg

Packaging quantity: 1 pcs.

Function: Electronic

Mounting method: DIN rail

Width in number of modular spacings: 1

Built-in depth: 35 mm

Number of normally open contacts: -

Number of normally closed contacts: -

Number of change-over contacts: -

Control voltage 1: 230 V

Type of control voltage 1: AC

Frequency control voltage 1: 50 Hz

Control voltage 2: -

Type of control voltage 2: -

Frequency control voltage 2: -

Rated switch current: 10 A

Max. switching current (cos phi = 0.6): -

Release-delay: -

Push button glow-lamp current: -

Wiring system: 4 wire configuration

Pre-warning of switching-off: Dimming up to 50 %

Current surge function selectable: -

Repetitive: -

Supply voltage: -

Voltage type of supply voltage: AC

Max. incandescent lamp load: 1500 W

Max. load fluorescent lamp: 350 VA

Max. load fluorescent lamp (Duo circuit): 650 VA

Max. load fluorescent lamp (parallel compensated): 500 VA
